Tower - 1 x Xeon E5-1630V4 / 3.7 GHz - RAM 16 GB - SSD 256 GB - TCG Opal Encryption - DVD-Writer - Quadro P2000 - GigE - Win 7 Pro 64-bit (includes Win 10 Pro 64-bit License) - monitor: none - TopSeller
|
.png)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.png)
.png)
Lenovo Premier Support with Onsite NBD
Lenovo Premier Support + Keep Your Drive
Lenovo Onsite + Accidental Damage Protection + Keep Your Drive + Premier SupportE5 based platform offering customers the lowest cost entry point into a mainstream market segment offering higher core count, higher memory capacity and more storage options than the Entry workstation space
Target Audience
Users looking for high performance/ high reliability mainstream workstations at a reasonable price point
Someone who wants
Faster and more powerful mainstream configuration than their current entry-level workstation to enhance overall performance
Flexibility of configuration
Maximum uptime on their workstations.
ISV certified systems
Price/ Performance Leadership.
The P410 is a solid, worry-free performer that can handle even daunting workload. High-quality processors with graphics deliver powerful performance, fully customizable storage, memory, power and I/O configurations.
Closing the gap between price and performance, the ThinkStation P410 offers powerful processor and higher memory capacity. It's a mainstream workstation at an entry-level price.
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkStation P410 - tower - Xeon E5-1630V4 3.7 GHz - 16 GB - SSD 256 GB - US |
| Type | Workstation - tower |
| Localization | Language: English / region: United States |
| Processor | 1 x Intel Xeon E5-1630V4 / 3.7 GHz (4 GHz) (Quad-Core) |
| Cache Memory | 10 MB |
| Cache Per Processor | 10 MB |
| RAM | 16 GB (installed) / 128 GB (max) - DDR4 SDRAM - ECC |
| Storage Controller | RAID (SATA 6Gb/s) |
| Hard Drive | SSD 256 GB - SATA 6Gb/s - 2.5" - TCG Opal Encryption |
| Optical Storage | DVD-Writer |
| Card Reader | 9 in 1 |
| Graphics Controller | NVIDIA Quadro P2000 |
| Video Memory | 5 GB |
| Audio Output | Stereo |
| Networking | GigE |
| Keyboard | US |
| Power | AC 120/230 V (50/60 Hz) |
| OS Provided | Microsoft Windows 7 Professional 64-bit Edition (downgrade from Windows 10 Pro 64-bit) + Windows 10 Pro 64-bit License |
| Dimensions (WxDxH) | 6.9 in x 16.8 in x 14.8 in |
| Weight | 30.86 lbs |
| Manufacturer Selling Program | TopSeller |
| Manufacturer Warranty | Limited warranty - 3 years - on-site - response time: next business day |
| General | |
| Type | Workstation |
| Product Form Factor | Tower |
| Embedded Security | Trusted Platform Module (TPM 1.2) Security Chip |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Bays | 2 (total) / 1 (free) x external 5.25" ¦ 2 (total) / 1 (free) x internal 3.5" |
| Slots | 2 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 4 (total) / 2 (free) x DIMM 288-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 2.0 x4 - half-length, full-height |
| Interfaces | 6 x USB 3.0 (2 front, 4 rear) ¦ 2 x microphone (1 front, 1 rear) ¦ 2 x USB 2.0 ¦ 1 x headphones (1 in front) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x audio line-in (1 rear) ¦ 1 x audio line-out (1 rear) ¦ 4 x Mini DisplayPort |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years - on-site - response time: next business day |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, GREENGUARD |
| Manufacturer Selling Program | TopSeller |
| RAM | |
| Installed Size | 16 GB / 128 GB (max) |
| Technology | DDR4 SDRAM - ECC |
| Effective Memory Speed | 2400 MHz |
| Rated Memory Speed | 2400 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 2 (empty) |
| Features | Registered, quad channel memory architecture |
| Configuration Features | 2 x 8 GB |
| Networking | |
| Ethernet Controller | Intel I218-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL) |
| Power | |
| Device Type | Power supply |
| Nominal Voltage | AC 120/230 V (50/60 Hz) |
| Power Provided | 450 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Efficiency | 92% |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 80% (non-condensing) |
| Storage Controller | |
| Type | 1 x RAID |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Cache Memory | |
| Installed Size | 10 MB |
| Cache Per Processor | 10 MB |
| Optical Storage | |
| Type | DVD-Writer DVD-Writer - SATA |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | NVIDIA Quadro P2000 |
| Video Memory | 5 GB |
| Video Interfaces | DisplayPort |
| Audio Output | |
| Sound Output Mode | Stereo |
| Operating System / Software | |
| OS Provided | Microsoft Windows 7 Professional 64-bit Edition (available through downgrade rights from Windows 10 Pro 64-bit) + Windows 10 Pro 64-bit License |
| Hard Drive | |
| Type | SSD - 2.5" |
| Capacity | 1 x 256 GB |
| Interface Type | SATA 6Gb/s |
| Features | TCG Opal Encryption |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 6.9 in |
| Depth | 16.8 in |
| Height | 14.8 in |
| Weight | 30.86 lbs |
| Keyboard | |
| Interface | USB |
| Localization & Layout | US |
| Card Reader | |
| Type | 9 in 1 card reader |
| Mouse | |
| Technology | Optical |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Xeon E5-1630V4 / 3.7 GHz |
| Max Turbo Speed | 4 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Chipset Type | Intel C612 |
