Storage controller (RAID) - 8 Channel - SATA 6Gb/s / SAS 12Gb/s low profile - 1.2 GBps - RAID 0, 1, 5, 6, 10, 50, 60 - PCIe 3.0 x8 - for PowerEdge C4130, R230, R630, T130, T330, T430, T630
| Main Specifications | |
|---|---|
| Product Description | Dell PERC H730 - storage controller (RAID) - SATA 6Gb/s / SAS 12Gb/s - PCIe 3.0 x8 |
| Device Type | Storage controller (RAID) - plug-in card - low profile |
| Bus Type | PCIe 3.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| Data Transfer Rate | 12 Gbit/s |
| Buffer Size | 1 GB |
| Supported Devices | Disk array (RAID) |
| Channel Qty | 8 |
| Max Storage Devices Qty | 255 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| System Requirements | Microsoft Windows Server 2008 R2 SP1, SuSE Linux Enterprise Server 10 SP4, Microsoft Windows Server 2012, Red Hat Enterprise Linux 5.8, VMware ESXi 5.1, Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP3, Red Hat Enterprise Linux 6.5 |
| Dimensions (WxDxH) | 6.6 in x 2.5 in |
| Designed For | PowerEdge T630; PowerEdge R230 |
| General | |
| Device Type | Storage controller (RAID) - plug-in card - low profile |
| Host Bus | PCIe 3.0 x8 |
| Expansion / Connectivity | |
| Interfaces | 2 x SATA 6Gb/s / SAS 12Gb/s - 4 x Mini SAS HD (SFF-8643) (internal) |
| Miscellaneous | |
| Features | DDF compliant Configuration on Disk (COD), Online Capacity Expansion (OCE), Online RAID Level Migration (RLM) |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2008 R2 SP1, SuSE Linux Enterprise Server 10 SP4, Microsoft Windows Server 2012, Red Hat Enterprise Linux 5.8, VMware ESXi 5.1, Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP3, Red Hat Enterprise Linux 6.5 |
| Environmental Parameters | |
| Max Operating Temperature | 140 °F |
| Storage Controller | |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| Data Transfer Rate | 12 Gbit/s |
| Buffer Size | 1 GB |
| Supported Devices | Disk array (RAID) |
| Channel Qty | 8 |
| Max Storage Devices Qty | 255 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Processor | LSI LSISAS3108 |
| Dimensions & Weight | |
| Depth | 6.6 in |
| Height | 2.5 in |
| Compatibility Information | |
| Designed For | Dell PowerEdge T630 ¦ Dell EMC PowerEdge R230 |
